Looking for dealer level coverage on Sea Doo marine engines? We got you covered with our portable tablet diagnostic scan tool. This tool will give you the power of the OEM dealer by allowing you to do what dealers can do such as perform diagnostic tests, read & clear fault codes, view live data, and much more.

Functionality

• Read Codes/Clear Codes
• Perform Service Resets
• Functional Commands: Brake Bleeding, IBR Configuration, Key Configuration, Minimum/Maximum History, Set Engine Location, RPM History, Reset Supercharge maintenance, and more (Depends on model & year of the engine).
• View ECU Information
• Create engine health reports and engine runtime reports
• View Live Data - Includes all sensors and values such as oil pressure, throttle position, intake pressure, and many more. Includes the ability to view data in multiple formats (Table View, Graph View, Instrument View, etc...)


Technical Specifications

• Size: 5.0"
• Resolution: 800 x 480
• Operating System: Android 5.1.1
• CPU: RK3128 Quad Core ARM Cortex A7
• Battery: 2600ma
• Operating Temperature: 14 to 131 degrees Fahrenheit
• Other: Touch screen, WIFI
• Includes 4-pin diagnostic cable, 8-pin diagnostic cable and charger for tablet

Demo Video:

Other

• Includes 2 years of Updates & Support

• Support most models from 2002 up to 2018
• Connects to Sea Doo and SportBoat Models

Registration and Set-up

View the video below on how to properly Register and Set-up the MINI Scan Tool
